Rooting and installing CWM on Samsung Galaxy S3 without Odin/Computer/USB connection

Are you totally new to rooting Android phones ? Can’t fully understand the whole new terminology ? Finding Odin Confusing ?……

Then this thread is for you !

I am assuming you already did you research about rooting and you know all the risks involved .

I am also assuming that you got stuck with some Odin errors like the Stuck at “Get PIT for Mapping” or any other issue , despite of this post I still recommend using Odin as it’s widely supported . Finally , I am not responsible for any damage that happens to your phone . This method worked for an S3 I9300 with Android JB 4.1.2.

Now after you have been lectured with the usual warnings and recommendations it’s time for action :

FIRST STEP : Downloading and installing Farmaroot.apk

Farmaroot is a tool that uses software workarounds to root the phone without having to flash a custom ROM.

1 – Download Farmaroot-1.6.0

2- Connect your phone to the PC and copy Farmaroot-1.6.0.apk to your sdcard .

3 – Install Farmaroot (make sure you checked installation from untrusted source from the security settings) .

4-  Run the app , choose “install Superuser”  option inside Framaraoot and Select any of the exploits that appears in the app and wait for some time(sam worked for me) .

  • If you get a “Success  … Superuser and su binary installed. You have to reboot your device” then you have successfully rooted your phone .

5- you can ensure that your phone is rooted by downloading the root checker from the app store.



SECOND STEP : Flashing the Clockworkmod recovery.

1- Now you have your phone rooted you can simply install CWM using the ROM manager app from the play store which fully supports the i9300 . Run Rom manager and follow the steps to flash the CWM.

2- Reboot your phone in recovery (by pressing Home + power + vol down buttons) and you will get the CWM recovery screen ..



That’s it ! Congrats !



Building android-4.0.4 IceCreamSandwich on Pandaboard/Pandaboard ES

This is the 2nd post about building Android for pandaboard. I quote from the previous post

Google maintainers advise to always repo sync the master branch for panda claiming it’s the most stable , but in my opinion they should focus on stabilizing tags. Tags should represent a stable snapshot of he source tree to build and run . That’s what a tag means in Software Engineering anyway !

This post is a translated version of the Japanese post on blog.sola-dolphin-1.net reposted under permission of the main author  that describes how to build Android JB tag android-4.0.4_r1.2 for pandaboard, of course some patching is required to get it work, you can download all the patches required from this mirror or follow the steps to get them one by one from the main mirror.

android-4.0.4

IMPORTANT: To compile ICS you need to be using gcc 4.4 , so you may downgrade your gcc version or just installing gcc/gcc++ 4.4 and specifying them while making.

$ sudo apt-get install gcc-4.4 gcc-4.4-multilib g++-4.4 g++-4.4-multilib


Then, override make’s default variables with

$ make CC=gcc-4.4 CXX=g++-4.4 -j4

– prepare the directory

$ mkdir ~/panda_work
$ export PANDA_WORK=~/panda_work
$ mkdir ~/panda_work/android
$ export ANDROID_ROOT=~/panda_work/android

– init the repo

$ cd $ANDROID_ROOT
$ repo init -u https://android.googlesource.com/platform/manifest -b android-4.2.2_r1
$ repo sync

notes:

  1. to save time you can use an old tree and repo init inside it’s dir , then sync will grab only the differences
  2. in case repo sync hangs use repo sync -j1 to disable multi threading also check repo sync -h for other options

– get the gpu user space binaries

$ wget https://dl.google.com/dl/android/aosp/imgtec-panda-20120430-67545da7.tgz
$ tar zxvf imgtec-panda-20120430-67545da7.tgz
$ ./extract-imgtec-panda.sh

– apply the patches

$ wget http://android-development-environment.googlecode.com/files/panda.ics.patch.tar.bz2
$ tar jxvf panda.ics.patch.tar.bz2
$ cd device/ti/panda
$ git apply panda.ics.patch/0001-merge-master-to-device-ti-panda.patch # merges the contents of master branch into /device/ti/panda
$ cd ..
$ tar jxvf panda.ics.patch/hardware_ti_wlan.tar.bz2 -C hardware/ti/ # merges the contents of master branch
$ tar jxvf panda.ics.patch/hardware_ti_wpan.tar.bz2 -C hardware/ti/ # merges the contents of master branch
$ git apply panda.ics.patch/0003-Change-ALOG-to-LOG.patch # fixes a bug
$ git apply panda.ics.patch/0004-enable-wifi.patch # merges the contents of master branch to enable wifi
$ git apply panda.ics.patch/0005-change-console-permission.patch # root permssion to console

– add the script of flashing or you can use fastboot instead , but note that this script will create an extra partition (/media)

$ git apply panda.ics.patch/0008-add-mksdcard_pandaboard.sh.patch

– build the tree

$ cd $ANDROID_ROOT
$ source build/envsetup.sh
$ lunch full_panda-userdebug
$ make CC=gcc-4.4 CXX=g++-4.4 -j4

– format and flash from a ubuntu machine, /dev/sdx is the the sdcard device

$ LANG=C sudo ./mksdcard_pandaboard.sh /dev/sdX $ANDROID_ROOT

kernel

– prepare the environment

$ export ARCH=arm
$ export CROSS_COMPILE=$ANDROID_ROOT/prebuilt/linux-x86/toolchain/arm-eabi-4.4.3/bin/arm-eabi-

– clone the repo

$ cd $PANDA_WORK
$ git clone https://android.googlesource.com/kernel/omap.git kernel
$ cd kernel
$ git checkout -b android-omap-panda-3.0 origin/android-omap-panda-3.0
$ git checkout 52f476403350050beb0dff135a55c06c9e7a82a9

– build

$ make panda_defconfig
$ make -j4
$ cp -a arch/arm/boot/zImage $ANDROID_ROOT/device/ti/panda/kernel

note: though bootloader and xloader images are provided within device/ti/panda dir , you can build them from source using the following instructions

xloader

– build xloader

$ cd $PANDA_WORK
$ git clone git://git.omapzoom.org/repo/x-loader.git
$ cd x-loader
$ git checkout -b omap4_dev origin/omap4_dev
$ make omap4430panda_config
$ make ift
$ cp -a MLO $ANDROID_ROOT/device/ti/panda/xloader.bin

bootlader(uboot)

– clone the repo

$ cd $PANDA_WORK
$ git clone git://git.omapzoom.org/repo/u-boot.git
$ cd u-boot
$ git checkout -b omap4_dev origin/omap4_dev

– change the boot parameters

$ wget http://android-development-environment.googlecode.com/files/0001-change-bootarges.patch
$ git apply 0001-change-bootarges.patch

– build

$ make omap4430panda_config
$ make
$ cp -a u-boot.bin $ANDROID_ROOT/device/ti/panda/bootloader.bin

Building android-4.2.2 JellyBean on Pandaboard/Pandaboard ES

Google maintainers advise to always repo sync the master branch for panda claiming it’s the most stable , but in my opinion they should focus on stabilizing tags. Tags should represent a stable snapshot of he source tree to build and run . That’s what a tag means in Software Engineering anyway !

This post is a translated version of the Japanese post on blog.sola-dolphin-1.net reposted under permission of the main author  that describes how to build Android JB tag android-4.2.2_r1 for pandaboard, of course some patching is required to get it work, you can download all the patches required from this mirror or follow the steps to get them one by one from the main mirror.

android-4.2.2

– prepare the directory

$ mkdir ~/panda_work
$ export PANDA_WORK=~/panda_work
$ mkdir ~/panda_work/android
$ export ANDROID_ROOT=~/panda_work/android

– init the repo

$ cd $ANDROID_ROOT
$ repo init -u https://android.googlesource.com/platform/manifest -b android-4.2.2_r1
$ repo sync

notes:

  1. to save time you can use an old tree and repo init inside it’s dir , then sync will grab only the differences
  2. in case repo sync hangs use repo sync -j1 to disable multi threading also check repo sync -h for other options

– get the gpu user space binaries

$ wget https://dl.google.com/dl/android/aosp/imgtec-panda-20120807-c4e99e89.tgz
$ tar zxvf imgtec-panda-20120807-c4e99e89.tgz
$ ./extract-imgtec-panda.sh

– apply the patches

$ cd $ANDROID_ROOT/build/
$ wget http://sola-dolphin-1.net/data/Panda/0001-panda-jb4.2_build.patch
$ git apply 0001-panda-jb4.2_build.patch
$ cd $ANDROID_ROOT/device/ti/panda/
$ wget http://sola-dolphin-1.net/data/Panda/0001-panda-jb4.2_device-ti-panda.patch
$ git apply 0001-panda-jb4.2_device-ti-panda.patch
$ cd $ANDROID_ROOT/hardware/ti/omap4xxx/
$ wget http://sola-dolphin-1.net/data/Panda/0001-panda-jb4.2_hardware-ti-omap4xxx.patch
$ git apply 0001-panda-jb4.2_hardware-ti-omap4xxx.patch
$ cd $ANDROID_ROOT/hardware/ti/wpan/
$ wget http://sola-dolphin-1.net/data/Panda/0001-panda-jb4.2_hardware-ti-wpan.patch
$ git apply 0001-panda-jb4.2_hardware-ti-wpan.patch

– you can either use fastboot to format and flash the images or use this script instead

$ cd $ANDROID_ROOT
$ wget http://sola-dolphin-1.net/data/Panda/0001-add-mksdcard_pandaboard.sh.patch
$ git apply 0001-add-mksdcard_pandaboard.sh.patch

– build the tree

$ cd $ANDROID_ROOT
$ source build/envsetup.sh
$ lunch full_panda-userdebug
$ make -j4

– format and flash from a ubuntu machine, /dev/sdx is the the sdcard device

$ LANG=C sudo ./mksdcard_pandaboard.sh /dev/sdX $ANDROID_ROOT

kernel

– prepare the environment

$ export ARCH=arm
$ export CROSS_COMPILE=$ANDROID_ROOT/prebuilts/gcc/linux-x86/arm/arm-eabi-4.6/bin/arm-eabi-

– clone the repo

$ cd $PANDA_WORK
$ git clone https://android.googlesource.com/kernel/omap.git kernel
$ cd kernel
$ git checkout -b android-omap-panda-3.0 origin/android-omap-panda-3.0

– build with panda config

$ make panda_defconfig
$ make
$ cp -a arch/arm/boot/zImage $ANDROID_ROOT/device/ti/panda/kernel

note: though bootloader and xloader images are provided within device/ti/panda dir , you can build them from source using the following instructions

xloader

– build xloader

$ cd $PANDA_WORK
$ git clone git://git.omapzoom.org/repo/x-loader.git
$ cd x-loader
$ git checkout -b omap4_dev origin/omap4_dev
$ make omap4430panda_config
$ make ift
$ cp -a MLO $ANDROID_ROOT/device/ti/panda/xloader.bin

bootlader(uboot)

– clone the repo

$ cd $PANDA_WORK
$ git clone git://git.omapzoom.org/repo/u-boot.git
$ cd u-boot
$ git checkout -b omap4_dev origin/omap4_dev

– change the boot parameters

$ wget http://android-development-environment.googlecode.com/files/0001-change-bootarges.patch
$ git apply 0001-change-bootarges.patch

– build

$ make omap4430panda_config
$ make
$ cp -a u-boot.bin $ANDROID_ROOT/device/ti/panda/bootloader.bin

Android Build System Ultimate Guide

Lately, Android Open Source Project has gone through various changes. For instance, Since JB Google decided to replace bluez bluetooth stack with an open source stack implemented by Broadcom claiming that the later is more optimized for Android devices causing a headache and new bugs for many users and developers, also there are frequent architectural changes (for example : the HAL layer) and so on…

The one fact that proved not to change through Android Open Source project lifetime is that it’s documentation is very poor and that was the main reason for me compiling this document from various blogs, android docs (which are gratefully referred to at the end of the page) and my own experience trying to produce as complete document as possible for the Android Build System including steps to build the source tree , some build tricks and hints!

Also, I tried to answer the famous question : “How do I add a java (or native) application into my android build ?

I hope this post shall be useful 🙂

Table Of Contents

Overview

The build system uses some pre-set environment variables and a series of ‘make’ files in order to build an Android system and prepare it for deployment to a platform.

Android make files end in the extension ‘.mk’ by convention, with the main make file in any particular source directory being named ‘Android.mk’.
There is only one official file named ‘Makefile’, at the top of the source tree for the whole repository. You set some environment variables, then type ‘make’ to build stuff. You can add some options to the make command line (other targets) to turn on verbose output, or perform different actions.

The build output is placed in ‘out/host’ and ‘out/target’ Stuff under ‘out/host’ are things compiled for your host platform (your desktop machine). Stuff under ‘out/target/product/<platform-name>’ eventually makes it’s way to a target device (or emulator).

The directory ‘out/target/product/<platform-name>/obj’ is used for staging “object” files, which are intermediate binary images used for building the final programs. Stuff that actually lands in the file system of the target is stored in the directories root, system, and data, under ‘out/target/product/<platform-name>’. Usually, these are bundled up into image files called system.img, ramdisk.img, and userdata.img.
This matches the separate file system partitions used on most Android devices.


Building Steps

In order to decide what to build, and how to build it, the build system requires that some variables be set. Different products, with different packages and options can be built from the same source tree. The variables to control this can be set via a file with declarations of ‘make’ variables, or can be specified in the environment.

envsetup

To set up your build environment, you need to load the variables and functions in build/envsetup.sh. Do this by ‘source-ing’ the file into your shell environment, like this:

$ source build/envsetup.sh

or

$ . build/envsetup.sh

You can type

$ hmm

at this point to see some utility functions that are available to make it easier to work with the source.

Invoke ". build/envsetup.sh" from your shell to add the following functions to your environment:
- lunch:   lunch <product_name>-<build_variant>
- tapas:   tapas [<App1> <App2> ...] [arm|x86|mips] [eng|userdebug|user]
- croot:   Changes directory to the top of the tree.
- m:       Makes from the top of the tree.
- mm:      Builds all of the modules in the current directory.
- mmm:     Builds all of the modules in the supplied directories.
- cgrep:   Greps on all local C/C++ files.
- jgrep:   Greps on all local Java files.
- resgrep: Greps on all local res/*.xml files.
- godir:   Go to the directory containing a file.

Look at the source to view more functions. The complete list is:
addcompletions add_lunch_combo cgrep check_product check_variant choosecombo chooseproduct choosetype choosevariant cproj croot findmakefile gdbclient
get_abs_build_var getbugreports get_build_var getlastscreenshot getprebuilt getscreenshotpath getsdcardpath gettargetarch gettop godir hmm
isviewserverstarted jgrep key_back key_home key_menu lunch _lunch m mm mmm pid printconfig print_lunch_menu resgrep runhat runtest set_java_home
setpaths set_sequence_number set_stuff_for_environment settitle smoketest startviewserver stopviewserver systemstack tapas tracedmdump

choosing target

To select the set of things you want to build, and what items to build for, you use either the ‘choosecombo’ function or the ‘lunch’ function. ‘choosecombo’ will walk you through the different items you have to select, one-by-one, while ‘lunch’ allows you select some pre-set combinations.
The items that have to be defined for a build are:
the product (‘generic’ or some specific board or platform name)
the build variant (‘user’, ‘userdebug’, or ‘eng’)
whether you’re running on a simulator (‘true’ or ‘false’)
the build type (‘release’ or ‘debug’)


Building Tricks

Seeing the actual commands used to build the software

Use the “showcommands” target on your ‘make’ line:

$ make -j4 showcommands

This can be used in conjunction with another make target, to see the commands for that build. That is, ‘showcommands’ is not a target itself, but just a modifier for the specified build.
In the example above, the -j4 is unrelated to the showcommands option, and is used to execute 4 make sessions that run in parallel.

Make targets

Here is a list of different make targets you can use to build different parts of the system:

make sdk - build the tools that are part of an SDK (adb, fastboot, etc.)
make snod - build the system image from the current software binaries
make services
make runtime
make droid - make droid is the normal build.
make all - make everything, whether it is included in the product definition or not
make clean - remove all built files (prepare for a new build). Same as rm -rf out/<configuration>/
make modules - shows a list of submodules that can be built (List of all LOCAL_MODULE definitions)
make <local_module> - make a specific module (note that this is not the same as directory name. It is the LOCAL_MODULE definition in the Android.mk file)
make clean-<local_module> - clean a specific module

Speeding up the build

You can use the ‘-j’ option with make, to start multiple threads of make execution concurrently.
You can also specify to use the ‘ccache’ compiler cache, which will speed up things once you have built things a first time. To do this, specify ‘export USE_CCACHE=1’ at your shell command line. (Note that ccache is included in the prebuilt section of the repository, and does not have to be installed on your host separately.)

Building only an individual program or module

If you use build/envsetup.sh, you can use some of the defined functions to build only a part of the tree. Use the ‘mm’ or ‘mmm’ commands to do this.
The ‘mm’ command makes stuff in the current directory (and sub-directories, I believe). With the ‘mmm’ command, you specify a directory or list of directories, and it builds those.

Build helper functions

A whole bunch of build helper functions are defined in the file build/core/definitions.mk
Try grep define build/core/definitions.mk for an exhaustive list.
Here is a snapshot of the file

###########################################################
## Find all of the java files from here.  Meant to be used like:
##    SRC_FILES := $(call all-subdir-java-files)
###########################################################

define all-subdir-java-files
$(call all-java-files-under,.)
endef

###########################################################
## Find all of the c files under the named directories.
## Meant to be used like:
##    SRC_FILES := $(call all-c-files-under,src tests)
###########################################################

define all-c-files-under
$(patsubst ./%,%, \
  $(shell cd $(LOCAL_PATH) ; \
          find $(1) -name "*.c" -and -not -name ".*") \
 )
endef

Build System Architecture

to be added….


How to add another component to the build

It’s simple to add a new java or native application to your android build , you just

  1. create the directory and copy your src files to it.
  2. then you should add the appropriate Android.mk file, the next section will help you to understand Android.mk files and write your own makefile.
  3. build the image and flash it to your device.

Template Android.mk files

  • Executable Template
LOCAL_PATH:= $(call my-dir)   # call function my-dir will return the path of Android.mk
include $(CLEAR_VARS)         # clean all variables mainly started with LOCAL_

LOCAL_SRC_FILES:= foo.c       # Source file list
LOCAL_MODULE:= foo            # The name of executable binary

include $(BUILD_EXECUTABLE)   # Start to build executable binary
  • Shared Library Template
LOCAL_PATH:= $(call my-dir)     # call function my-dir will return the path of Android.mk
include $(CLEAR_VARS)           # clean all variables mainly started with LOCAL_

LOCAL_SRC_FILES:= foo.c bar.c   # Source file list
LOCAL_MODULE:= libfoo           # The name of shared library
LOCAL_PRELINK_MODULE := false   # Prevent from prelink error

include $(BUILD_SHARED_LIBRARY) # Start to build shared library
  • Static Library Template
LOCAL_PATH:= $(call my-dir)     # call function my-dir will return the path of Android.mk
include $(CLEAR_VARS)           # clean all variables mainly started with LOCAL_

LOCAL_SRC_FILES:= $(call all-subdir-c-files)   # Source file list
LOCAL_MODULE:= libbar           # The name of static library
LOCAL_PRELINK_MODULE := false   # Prevent from prelink error

include $(BUILD_STATIC_LIBRARY) # Start to build static library
  • If you have a tool that generates a source file from an input file using a user specified tool
SRC := $(call my-dir)/include/vnd_generic.txt
GEN := $(intermediates)/vnd_buildcfg.h
TOOL := $(TOP_DIR)external/bluetooth/bluedroid/tools/gen-buildcfg.sh

$(GEN): PRIVATE_PATH := $(call my-dir)
$(GEN): PRIVATE_CUSTOM_TOOL = $(TOOL) $< $@
$(GEN): $(SRC)  $(TOOL)
    $(transform-generated-source)

LOCAL_GENERATED_SOURCES += $(GEN)
  • Adding a prebuilt library
   include $(CLEAR_VARS)
   LOCAL_MODULE := foo-prebuilt
   LOCAL_SRC_FILES := libfoo.so
   LOCAL_EXPORT_C_INCLUDES := $(LOCAL_PATH)/include
   include $(PREBUILT_SHARED_LIBRARY)

The LOCAL_EXPORT_C_INCLUDES definition here ensures that any module that
depends on the prebuilt one will have its LOCAL_C_INCLUDES automatically
prepended with the path to the prebuilt’s include directory, and will thus
be able to find headers inside that.

What is the LOCAL_MODULE_TAGS variable ?

we can add LOCAL_MODULE_TAGS variable to Android.mk file to determine that module to be installed in that source code built. Here are the some defined tags and their meanings

  • eng

– Default variant
– Installs modules tagged with: eng, debug, user, and/or development
– Installs non-apk modules that have no tags specified.
– Installs APKs according to the product definition files.
– adb is enabled by default.

  • user

– Final release
– Installs modules tagged with user
– Installs non-apk modules that have no tags specified
– Install APKs according to the product definition files
– adb is disabled by default.

  • userdebug, Same as user except:

– Also installs modules tagged with debug
– adb is enabled by default

How to include a shared library in your component ?

LOCAL_SHARED_LIBRARIES := libfoo

How to include a static library in your component ?

LOCAL_STATIC_LIBRARIES
These are the static libraries that you want to include in your module.
Mostly, we use shared libraries, but there are a couple of places, like executables in sbin and host executables where we use static libraries instead.

LOCAL_STATIC_LIBRARIES := libbar

LOCAL_WHOLE_STATIC_LIBRARIES
These are the static libraries that you want to include in your module without allowing the linker to remove dead code from them.
This is mostly useful if you want to add a static library to a shared library and have the static library’s content exposed from the shared library.

LOCAL_WHOLE_STATIC_LIBRARIES := libbar

Include path list

LOCAL_C_INCLUDES += \
                    usr/include           \
                    usr/local/include     \
                    $(LOCAL_PATH)/include

Using c/cpp/cxx/ld flags

LOCAL_CFLAGS   += -DONLY_C_NEEDED
LOCAL_CXXFLAGS += -DONLY_CXX_NEEDED
LOCAL_CPPFLAGS += -DBOTH_C_CXX_NEEDED
LOCAL_LDFLAGS  += -Wl,--exclude-libs=libgcc_eh.a
LOCAL_LDLIBS   += -lpthread

Call subdir’s Android.mk

Not recursively, just the directly sudir.

include $(call all-subdir-makefiles)

A full list of Android.mk variables

These are the variables that you’ll commonly see in Android.mk files, listed alphabetically.

But first, a note on variable naming:

LOCAL_ – These variables are set per-module. They are cleared by the include $(CLEAR_VARS) line, so you can rely on them being empty after including that file. Most of the variables you’ll use in most modules are LOCAL_ variables.
PRIVATE_ – These variables are make-target-specific variables. That means they’re only usable within the commands for that module. It also means that they’re unlikely to change behind your back from modules that are included after yours. Check the make documentation to find more about target-specific variables.
INTERNAL_ – These variables are critical to functioning of the build system, so you shouldn’t create variables named like this, and you probably shouldn’t be messing with these variables in your makefiles.
HOST_ and TARGET_ – These contain the directories and definitions that are specific to either the host or the target builds. Do not set variables that start with HOST_ or TARGET_ in your makefiles.
BUILD_ and CLEAR_VARS – These contain the names of well-defined template makefiles to include. Some examples are CLEAR_VARS and BUILD_HOST_PACKAGE.
Any other name is fair-game for you to use in your Android.mk. However, remember that this is a non-recursive build system, so it is possible that your variable will be changed by another Android.mk included later, and be different when the commands for your rule / module are executed.

1 – NDK-provided variables:

These GNU Make variables are defined by the build system before

your Android.mk file is parsed. Note that under certain circumstances
the NDK might parse your Android.mk several times, each with different
definition for some of these variables.

CLEAR_VARS
Points to a build script that undefines nearly all LOCAL_XXX variables
listed in the “Module-description” section below. You must include
the script before starting a new module, e.g.:

include $(CLEAR_VARS)

BUILD_SHARED_LIBRARY
Points to a build script that collects all the information about the
module you provided in LOCAL_XXX variables and determines how to build
a target shared library from the sources you listed. Note that you
must have LOCAL_MODULE and LOCAL_SRC_FILES defined, at a minimum before
including this file. Example usage:

include $(BUILD_SHARED_LIBRARY) #Note that this will generate a file named lib$(LOCAL_MODULE).so

BUILD_STATIC_LIBRARY
A variant of BUILD_SHARED_LIBRARY that is used to build a target static
library instead. Static libraries are not copied into your
project/packages but can be used to build shared libraries (see
LOCAL_STATIC_LIBRARIES and LOCAL_WHOLE_STATIC_LIBRARIES described below).
Example usage:

include $(BUILD_STATIC_LIBRARY) #Note that this will generate a file named lib$(LOCAL_MODULE).a

PREBUILT_SHARED_LIBRARY
Points to a build script used to specify a prebuilt shared library.
Unlike BUILD_SHARED_LIBRARY and BUILD_STATIC_LIBRARY, the value
of LOCAL_SRC_FILES must be a single path to a prebuilt shared
library (e.g. foo/libfoo.so), instead of a source file.
You can reference the prebuilt library in another module using
the LOCAL_PREBUILTS variable (see docs/PREBUILTS.html for more information).

PREBUILT_STATIC_LIBRARY
This is the same as PREBUILT_SHARED_LIBRARY, but for a static library
file instead. See docs/PREBUILTS.html for more.

TARGET_ARCH
Name of the target CPU architecture as it is specified by the
full Android open-source build. This is ‘arm’ for any ARM-compatible
build, independent of the CPU architecture revision.

TARGET_PLATFORM
Name of the target Android platform when this Android.mk is parsed.
For example, ‘android-3’ correspond to Android 1.5 system images. For
a complete list of platform names and corresponding Android system
images, read docs/STABLE-APIS.html.

refer to /build/core/envsetup.mk for more TARGET_ variables

2 – NDK-provided function macros:

The following are GNU Make ‘function’ macros, and must be evaluated
by using ‘$(call <function>)’. They return textual information.

my-dir
Returns the path of the last included Makefile, which typically is
the current Android.mk’s directory. This is useful to define
LOCAL_PATH at the start of your Android.mk as with:

        LOCAL_PATH := $(call my-dir)

IMPORTANT NOTE: Due to the way GNU Make works, this really returns
the path of the last included Makefile during the parsing of
build scripts. Do not call my-dir after including another file. For example, consider the following example:

        LOCAL_PATH := $(call my-dir)

        ... declare one module

        include $(LOCAL_PATH)/foo/Android.mk

        LOCAL_PATH := $(call my-dir)

        ... declare another module

The problem here is that the second call to ‘my-dir’ will define
LOCAL_PATH to $PATH/foo instead of $PATH, due to the include that
was performed before that. For this reason, it’s better to put additional includes after
everything else in an Android.mk, as in:

        LOCAL_PATH := $(call my-dir)

        ... declare one module

        LOCAL_PATH := $(call my-dir)

        ... declare another module

        # extra includes at the end of the Android.mk
        include $(LOCAL_PATH)/foo/Android.mk

If this is not convenient, save the value of the first my-dir call
into another variable, for example:

        MY_LOCAL_PATH := $(call my-dir)

        LOCAL_PATH := $(MY_LOCAL_PATH)

        ... declare one module

        include $(LOCAL_PATH)/foo/Android.mk

        LOCAL_PATH := $(MY_LOCAL_PATH)

        ... declare another module

all-subdir-makefiles
Returns a list of Android.mk located in all sub-directories of
the current ‘my-dir’ path. For example, consider the following
hierarchy:

        sources/foo/Android.mk
        sources/foo/lib1/Android.mk
        sources/foo/lib2/Android.mk

If sources/foo/Android.mk contains the single line:

        include $(call all-subdir-makefiles)

Then it will include automatically sources/foo/lib1/Android.mk and
sources/foo/lib2/Android.mk This function can be used to provide deep-nested source directory
hierarchies to the build system. Note that by default, the NDK
will only look for files in sources/*/Android.mk

this-makefile
Returns the path of the current Makefile (i.e. where the function
is called).

parent-makefile
Returns the path of the parent Makefile in the inclusion tree,
i.e. the path of the Makefile that included the current one.

grand-parent-makefile
Guess what…

import-module
A function that allows you to find and include the Android.mk
of another module by name. A typical example is:

      $(call import-module,<name>)

And this will look for the module tagged <name> in the list of
directories referenced by your NDK_MODULE_PATH environment
variable, and include its Android.mk automatically for you. Read docs/IMPORT-MODULE.html for more details.

3 – Module-description variables

The following variables are used to describe your module to the build

system. You should define some of them between an ‘include $(CLEAR_VARS)’
and an ‘include $(BUILD_XXXXX)’. As written previously, $(CLEAR_VARS) is
a script that will undefine/clear all of these variables, unless explicitly
noted in their description.

LOCAL_ASSET_FILES

In Android.mk files that include $(BUILD_PACKAGE) set this to the set of files you want built into your app. Usually:

LOCAL_ASSET_FILES += $(call find-subdir-assets)

This will probably change when we switch to ant for the apps' build system.

LOCAL_CC

If you want to use a different C compiler for this module, set LOCAL_CC to the path to the compiler.
If LOCAL_CC is blank, the appropriate default compiler is used.

LOCAL_CXX

If you want to use a different C++ compiler for this module, set LOCAL_CXX to the path to the compiler.
 If LOCAL_CXX is blank, the appropriate default compiler is used.

LOCAL_CFLAGS

If you have additional flags to pass into the C or C++ compiler, add them here. For example:

LOCAL_CFLAGS += -DLIBUTILS_NATIVE=1

LOCAL_CPPFLAGS

If you have additional flags to pass into only the C++ compiler, add them here. For example:

LOCAL_CPPFLAGS += -ffriend-injection

LOCAL_CPPFLAGS is guaranteed to be after LOCAL_CFLAGS on the compile line, so you can use it to override flags listed in LOCAL_CFLAGS.

LOCAL_CPP_EXTENSION

If your C++ files end in something other than ".cpp", you can specify the custom extension here. For example:

LOCAL_CPP_EXTENSION := .cc

Note that all C++ files for a given module must have the same extension; it is not currently possible to mix different extensions.

LOCAL_NO_DEFAULT_COMPILER_FLAGS

Normally, the compile line for C and C++ files includes global include paths and global cflags.
If LOCAL_NO_DEFAULT_COMPILER_FLAGS is non-empty,
 none of the default includes or flags will be used when compiling C and C++ files in this module.
 LOCAL_C_INCLUDES, LOCAL_CFLAGS, and LOCAL_CPPFLAGS will still be used in this case,
 as will any DEBUG_CFLAGS that are defined for the module.

LOCAL_C_INCLUDES

Additional directories to instruct the C/C++ compilers to look for header files in.
These paths are rooted at the top of the tree.
 Use LOCAL_PATH if you have subdirectories of your own that you want in the include paths. For example:

LOCAL_C_INCLUDES += extlibs/zlib-1.2.3
LOCAL_C_INCLUDES += $(LOCAL_PATH)/src

You should not add subdirectories of include to LOCAL_C_INCLUDES,
 instead you should reference those files in the #include statement with their subdirectories.
For example:

#include <utils/KeyedVector.h>
not #include <KeyedVector.h>

There are some components that are doing this wrong, and should be cleaned up.

LOCAL_MODULE_TAGS

Set LOCAL_MODULE_TAGS to any number of whitespace-separated tags.
If the tag list is empty or contains droid, the module will get installed as part of a make droid.
Modules with the tag shell_$(TARGET_SHELL) will also be installed.
Otherwise, it will only get installed by running make <your-module> or with the make all pseudotarget.

LOCAL_REQUIRED_MODULES

Set LOCAL_REQUIRED_MODULES to any number of whitespace-separated module names, like "libblah" or "Email".
 If this module is installed, all of the modules that it requires will be installed as well.
This can be used to, e.g., ensure that necessary shared libraries or providers are installed when a given app is installed.

LOCAL_FORCE_STATIC_EXECUTABLE

If your executable should be linked statically, set LOCAL_FORCE_STATIC_EXECUTABLE:=true.
There is a very short list of libraries that we have in static form (currently only libc).
 This is really only used for executables in /sbin on the root filesystem.

LOCAL_GENERATED_SOURCES

Files that you add to LOCAL_GENERATED_SOURCES will be automatically generated and then linked in when your module is built.
 See the Custom Tools template makefile for an example.

LOCAL_JAVACFLAGS

If you have additional flags to pass into the javac compiler, add them here. For example:

LOCAL_JAVACFLAGS += -Xlint:deprecation

LOCAL_JAVA_LIBRARIES

When linking Java apps and libraries, LOCAL_JAVA_LIBRARIES specifies which sets of java classes to include.
 Currently there are two of these: core and framework. In most cases, it will look like this:

LOCAL_JAVA_LIBRARIES := core framework

Note that setting LOCAL_JAVA_LIBRARIES is not necessary (and is not allowed) when building an APK with "include $(BUILD_PACKAGE)".
 The appropriate libraries will be included automatically.

LOCAL_LDFLAGS

You can pass additional flags to the linker by setting LOCAL_LDFLAGS.
Keep in mind that the order of parameters is very important to ld, so test whatever you do on all platforms.

LOCAL_LDLIBS

LOCAL_LDLIBS allows you to specify additional libraries that are not part of the build for your executable or library.
 Specify the libraries you want in -lxxx format; they're passed directly to the link line.
 However, keep in mind that there will be no dependency generated for these libraries.
It's most useful in simulator builds where you want to use a library preinstalled on the host.
The linker (ld) is a particularly fussy beast, so it's sometimes necessary to pass other flags here if you're doing something sneaky. Some examples:

LOCAL_LDLIBS += -lcurses -lpthread
LOCAL_LDLIBS += -Wl,-z,origin

LOCAL_NO_MANIFEST

If your package doesn't have a manifest (AndroidManifest.xml), then set LOCAL_NO_MANIFEST:=true.
The common resources package does this.

LOCAL_PACKAGE_NAME

LOCAL_PACKAGE_NAME is the name of an app. For example, Dialer, Contacts, etc.
This will probably change or go away when we switch to an ant-based build system for the apps.

LOCAL_PATH

The directory your Android.mk file is in. You can set it by putting the following as the first line in your Android.mk:

LOCAL_PATH := $(my-dir)

The my-dir macro uses the MAKEFILE_LIST variable, so you must call it before you include any other makefiles.
 Also, consider that any subdirectories you inlcude might reset LOCAL_PATH, so do your own stuff before you include them.
 This also means that if you try to write several include lines that reference LOCAL_PATH, it won't work,
 because those included makefiles might reset LOCAL_PATH.

LOCAL_POST_PROCESS_COMMAND

For host executables, you can specify a command to run on the module after it's been linked.
 You might have to go through some contortions to get variables right because of early or late variable evaluation:

module := $(HOST_OUT_EXECUTABLES)/$(LOCAL_MODULE)
LOCAL_POST_PROCESS_COMMAND := /Developer/Tools/Rez -d __DARWIN__ -t APPL\
       -d __WXMAC__ -o $(module) Carbon.r

LOCAL_PREBUILT_EXECUTABLES

When including $(BUILD_PREBUILT) or $(BUILD_HOST_PREBUILT), set these to executables that you want copied.
 They're located automatically into the right bin directory.

LOCAL_PREBUILT_LIBS

When including $(BUILD_PREBUILT) or $(BUILD_HOST_PREBUILT), set these to libraries that you want copied.
 They're located automatically into the right lib directory.

LOCAL_SHARED_LIBRARIES

These are the libraries you directly link against. You don't need to pass transitively included libraries.
 Specify the name without the suffix:

LOCAL_SHARED_LIBRARIES := \
    libutils \
    libui \
    libaudio \
    libexpat \
    libsgl

LOCAL_SRC_FILES

The build system looks at LOCAL_SRC_FILES to know what source files to compile -- .cpp .c .y .l .java. For lex and yacc files,
 it knows how to correctly do the intermediate .h and .c/.cpp files automatically.
If the files are in a subdirectory of the one containing the Android.mk, prefix them with the directory name:

LOCAL_SRC_FILES := \
    file1.cpp \
    dir/file2.cpp

LOCAL_STATIC_LIBRARIES

These are the static libraries that you want to include in your module.
Mostly, we use shared libraries, but there are a couple of places,
like executables in sbin and host executables where we use static libraries instead.

LOCAL_STATIC_LIBRARIES := \
    libutils \
    libtinyxml

LOCAL_MODULE

LOCAL_MODULE is the name of what's supposed to be generated from your Android.mk.
For exmample, for libkjs, the LOCAL_MODULE is "libkjs" (the build system adds the appropriate suffix -- .so .dylib .dll).
For app modules, use LOCAL_PACKAGE_NAME instead of LOCAL_MODULE.

LOCAL_MODULE_PATH

Instructs the build system to put the module somewhere other than what's normal for its type.
If you override this, make sure you also set LOCAL_UNSTRIPPED_PATH if it's an executable or a shared library
so the unstripped binary has somewhere to go. An error will occur if you forget to.

LOCAL_UNSTRIPPED_PATH

Instructs the build system to put the unstripped version of the module somewhere other than what's normal for its type.
 Usually, you override this because you overrode LOCAL_MODULE_PATH for an executable or a shared library.
 If you overrode LOCAL_MODULE_PATH, but not LOCAL_UNSTRIPPED_PATH, an error will occur.

LOCAL_WHOLE_STATIC_LIBRARIES

These are the static libraries that you want to include in your module without allowing the linker to remove dead code from them.
This is mostly useful if you want to add a static library to a shared library and have the static library's content exposed from the shared library.

LOCAL_WHOLE_STATIC_LIBRARIES := \
    libsqlite3_android

LOCAL_YACCFLAGS

Any flags to pass to invocations of yacc for your module.
 A known limitation here is that the flags will be the same for all invocations of YACC for your module.
 This can be fixed. If you ever need it to be, just ask.

LOCAL_YACCFLAGS := -p kjsyy

references

https://sites.google.com/site/fourdollars/android/android-mk

http://elinux.org/Android_Build_System

aosp/build/core/build-system.html
aosp/ndk/docs/ANDROID-MK.html
aosp/ndk/docs/PREBUILTS.html
